GEN 5 CAMARO

Upgrade your V-6 or SS Camaro’s suspension with the same parts used in the 1LE Track Pack. This kit features a stiffer 27mm solid front stabilizer bar and a 28mm solid rear stabilizer bar for improved body control in cornering. The front struts were redesigned with improved damping curves for more body control and quicker response times. It also includes faster reacting rear monotube shocks to replace the V-6 and SS twin-tube design and combines them with a stiffer rear upper shock mount to increase vehicle agility, both are shared with the ZL1. The bushings in the rear toe link are replaced with spherical bushings to eliminate compliance in cornering, which is also common with the ZL1. The V-6 kit also includes the stiffer front springs used on the 1LE and SS variants. V6 System requires SS Brake Upgrade. 2010-2011 Gen 5 Camaro’s require service modification kit 23484878 for proper installation of the Z/28 and 1LE suspension kits.

PART NO. 23123398 / V6 (SHOWN)^†

PART NO. 23123397 / V8

Take your Camaro’s cornering ability to another level with this lightweight, aluminum underhood tower-to-tower brace. Sourced from the 1LE package, the Chevrolet Performance Strut Tower Brace adds chassis stiffness and a more-direct steering response by connecting the two front strut towers together. The piece is a direct bolt-on for 2010-and-newer SS and V-6 Camaros, and when paired with the 1LE Track Pack, it will make your Camaro handle like it’s on rails. NOTE: Does not void warranty.

PART NO. 23120485
from $150

The Z/28 is the first high-volume production road car to employ racing-derived DSSV^® (Dynamic Suspensions Spool Valve) damper technology from Multimatic.™ The dampers rely upon a pair of self-piloted spool valves to control fluid through tuned port shapes rather than conventional deflected disc dampers. The design of the inverted-monotube front strut and aluminum-body monotube rear hydraulic dampers offers maximum response, stiffness, and tuning optimized for the track, with the highest level of damper predictability, accuracy, and repeatability. The unique dampers are the center of a comprehensive suspension package that also includes higher-rate coil springs, smaller-diameter solid stabilizer bars, and higher-rate suspension bushings. The dampers are matched with optimized stiff spring rates and stabilizer bars in both the front and rear to reduce body movement in hard cornering and acceleration. Also included in the package are front ride-and-handling links, rear upper control arms, rear trailing links, and toe links which have upgraded stiffer bushings designed to reduce cornering compliance and increase durability on the track. 2010-2011 Gen 5 Camaro’s require service modification kit 23484878 for proper installation of the Z/28 and 1LE suspension kits.

PART NO. 23464729
